Kanomax Portable Particle Counters – Models 3905 and 3910 are the smallest 6-channel portable particle counters in the industry. They measure particles at 1.0 CFM (28.3 LPM) and 1.77 CFM (50 LPM), respectively. Both models feature 0.3-micron minimum sensitivity, large color touch screens with a streamlined and user-friendly interface programmed with different standards to help guide users through the measuring and certification process.

An optional Climomaster hot-wire environmental sensor is available. It provides the ability to measure air velocity, temperature and humidity, making the 3900 Series Portable Particle Counters the ultimate tools for cleanroom certification.

Features & Benefits

0.3 µm, 0.5 µm, 1.0 µm, 3.0 µm, 5.0µm, 10.0µm

28.3 lpm (1.0 cfm) or 50 lpm (1.77 cfm) flow rate speeds the sampling process

Simultaneously measures and displays up to 6 particle sizes from 0.3 to 10 microns

Fully compliant with ISO 21501-4 calibration standard

Enables you to certify cleanrooms up to ISO Class 2

50LPM and 1 CFM flow rate respectively and a 0.3micron sensitivity.

Upload from blueprint your cleanroom layout

Optional CLIMOMASTER environmental sensor provides the ability to measure air velocity, temperature and humidity making these instruments the ultimate tools for cleanroom certification.

Intuitive ICON-driven screens and menus are easy to learn and simple to use

NIST TRACEABLE CALIBRATION Certificate* comes standard

3910/3905 can store up to 10,000 records of particle count data from up to 6 particle channels and the configurable recipe database can store up to 50 recipes for sampling and reports.

All data can be quickly and reliably transferred to a computer, a Facility Monitoring System or Building Automation System.

Secure data transfer to a USB Flash Drive

21 CFR Part 11 compliant with IQ/OQ documentation available

Built-in printer and onboard datalogging (up to 10,000 records) is standard on both 3910 /3905

Flexible communication with these instruments is made possible by the integrated Ethernet, RS-485, USB and Flash Drive memory card interfaces

Applications

Monitor and verify cleanrooms to meet ISO 14644: 2015 cleanroom classification

Monitor surgical rooms

Filter testing

IAQ investigation

Data center cleaning

Main Unit Specifications
